Description

Mk4, 3 Bag Unit

Width 725mm

Length 3440mm

Motor 7.5kw

Volume 5947 M3/H

Pressure 230mm

Filter Area 10 M2

Bag capacity 1.4 M3

Weight 325 kgs

Inlet size 315mm

Product Description

The process could not be simpler for the collection of chipboard and MDF sawdust to wood chippings.

All these units are fitted with powerful, self-cleaning fans to transport the waste material through a ductwork system into the unit for separation.
On entering the unit the bulk waste spins into polythene bags and the finer dust is filtered through Highglaze Terylene Needlefelt media to allow the air to return to the working area without heat loss.
air-diagram3Each unit is fitted with Inventair special swirl baffles which maximises even bag fill evenly with waste.
The units are supplied with their own D.O.L starter and spare polythene bags.
