New Minimax SC3C Panel Saw

230v Single Phase

Technical specification.

– with 1600mm Sliding Carriage

– 900mm rip to the right
– sawblade tilting 0-45 deg
– max diam sawblade 315mm
– max sawblade projection at 90 deg. 100mm
– max sawblade projection at 45 deg. 80mm
– main motor power 2.2kw (3hp)

Upgrades available on this machine:

2600mm sliding carriage

Self braking motor

Overhead blade protection

Scoring unit complete with 80mm diam sawblade

Ripping capacity on parallel fence 1270mm
