2021 SCM Minimax ME35TR Edgebander, Pre Milling, Corner Rounding, Edge and Glue Scraping, Anti Adhesive Unit

2021

0.4-3mm and up to 5mm solid strips

8-50mm max panel height

Feed speed 7m/min

3 Phase, 4kw

Operating temperature 20 – 190 degrees celcius

6.5 bar air supply

Exhaust outlet for glue pot 60mm

Trimming unit 2 x 60mm

Pre milling unit 2 x 80mm

Combined end cutting/rounding unit 60mm

Pre milling unit with 2 diamond tools 80mm diameter. 4 Possible removals 0.5/l/1.5/2mm thickness.

Combined end cutting-rounding unit – Cuts and rounds the edge in a single pass at the ends of the panel. It is possible to work with end cutting only.

Edge scraping

Glue scraping unit

Device for panel edge heating

Anti adhesive unit
